3-Wheel Dual-drive Counterbalance Forklift 1800kg
Estimated delivery within 1-2 weeks
3 year battery warranty
EP Store guaranteed local dealer
| Name | Value |
|---|---|
| Operator type | Seated |
| Load capacity | 1800 kg |
| Load centre distance | 500 mm |
| Load distance, centre of drive axle to fork | 420 mm |
| Wheelbase | 1330 mm |
| Service weight | 3269 kg |
| Axle loading, laden front/rear | 4415/654 kg |
| Axle loading, unladen front/rear | 1368/1901 kg |
| Tyre type | Solid rubber |
| Tyre size, front | 18X7-8mm |
| Tyre size, rear | 140/55-9mm |
| Wheels, number front/rear (x=drive wheels) | 2X/2 |
| Tread width, front | 943 mm |
| Tread width, rear | 210 mm |
| Max lift height | 6000 mm |
| Tilt of mast/fork carriage forward/backward | 6/6 ° |
| Retracted mast height | 2075 mm |
| Free lift | 100 mm |
| Lift height | 3000 mm |
| Height, mast extended | 4055 mm |
| Height of overhead guard (cabin) | 2078 mm |
| Seat height/standing height | 1050 mm |
| Tow coupling height | 600 mm |
| Overall length | 2833 mm |
| Length to face of forks | 1913 mm |
| Overall width | 1100 mm |
| Fork dimensions | 40X100X920 mm |
| A,B Fork carriage class/type A, B | 2A |
| Fork carriage width | 1040 mm |
| Ground clearance, laden, below mast | 89 mm |
| Ground clearance, centre of wheelbase | 92 mm |
| Aisle width for pallets 1000×1200 crossways | 3275 Ast |
| Aisle width for pallets 800×1200 lengthways | 3400 Ast |
| Turning radius | 1550 Wa |
| Travel speed, laden/unladen | 13/14 km/h |
| Lifting speed, laden/unladen | 0.33/0.45 m/s |
| Lowering speed, laden/unladen | 0.4/0.44 m/s |
| Max. gradeability, laden/unladen | 10/15 % |
| Service brake | Hydraulic |
| Parking brake | Mechanical |
| Drive motor rating S2 60 min | 5.0X2 kW |
| Lift motor rating at S3 15% | 11 kW |
| Battery nominal capacity | 205 Ah |
| Battery voltage | 80 V |
| Battery type | Li-Ion |
| Battery weight | 165 kg |
| Type of drive control | AC |
| Steering design | Hydraulic |
| Sound pressure level at the drivers ear | 70 dB(A) |
Explore the CPD18TVL
Powerful Performance
Large Workspace
Compact Size
Integrated Charger
South Australia
We have dealers in this area!
Victoria
We have dealers in this area!
Victoria
We have dealers in this area!
Victoria
We have dealers in this area!
Victoria
We have dealers in this area!
New South Wales
We have dealers in this area!
New South Wales
We have dealers in this area!
New South Wales
We have dealers in this area!
Queensland
We have dealers in this area!
Queensland
We have dealers in this area!
Western Australia
We have dealers in this area!
Our dedicated sales and support network for the CPD18TVL
With the support of EP Equipment distributors spread across the UK, you are guaranteed to receive fast assistance, personalised advice and original parts for your CPD18TVL.
More and more companies are replacing their old equipment with 100% electric solutions like the CPD18TVL, appreciated for their compactness, quiet operation and reduced operating costs.
Choosing the CPD18TVL means choosing a sustainable alternative, without compromising on power, versatility and autonomy.
Thanks to our network of partners in the UK, you benefit from:
- Fast delivery of trucks like the CPD18TVL
- Qualified and responsive technical support
- Constant availability of original spare parts
FAQs
What is the load capacity of the CPD15/18/20TVL series?
The CPD15/18/20TVL series offers a load capacity range from 1,500 kg to 2,000 kg, making it suitable for a wide variety of material handling applications. Each model is designed with a 500 mm load centre, ensuring exceptional stability and precise load control even when operating at full capacity.
What is the maximum lift height?
The CPD15/18/20TVL series provides a standard lift height of 3,000 mm, with optional mast configurations reaching up to 6,000 mm for the CPD18TVL and CPD20TVL. The high-strength mast design offers excellent visibility and stability, ensuring safe and efficient load handling at any height.
What type of battery powers the CPD15/18/20TVL series?
These forklifts are powered by an advanced 80V lithium-ion battery developed in-house by EP Equipment. The Li-ion system delivers strong performance, fast opportunity charging, and up to six hours of continuous operation per charge. A single-phase integrated charger allows convenient charging from any standard power outlet, making the trucks ideal for flexible warehouse use.
Does the CPD18TVL have an integrated charger?
Yes, the CPD18TVL features an integrated charger, allowing convenient opportunity charging during breaks without requiring separate charging infrastructure. This capability supports extended operating hours and makes the forklift particularly practical for rental applications and multi-shift operations where maximising uptime is essential.
How does the dual drive system benefit productivity?
The twin 5 kW motors provide significantly more tractive effort than single-motor forklifts, improving acceleration, gradeability, and responsiveness under load. This translates to faster cycle times and more confident operation on ramps and loading docks, particularly when handling loads approaching the 1,800 kg capacity.
