Compact 4-Wheel Electric Li-ion Forklift 1800kg – EFL181

$24,999

$22,880

+ GST

3 reviews

The EFL181 is a compact 4-wheel electric lithium-ion forklift designed for light to medium-duty applications across indoor environments and uneven outdoor yards. It features a 1800 kg lifting capacity, fast-charging LFP battery, and ultra-compact dimensions.

Get a QuoteRequest Info

Or download datasheet

Estimated delivery within 1-2 weeks

3 year battery warranty

EP Store guaranteed local dealer

Capacity
1800 kg

Lift height
4800 mm

Battery
150 Ah 48 V

Fork dimensions
1150 mm

Ground clearance
120 mm

Velocity
9 km/h

Name	Value
Operator type	Seated
Load capacity	1800 kg
Load centre distance	500 mm
Load distance, centre of drive axle to fork	405 mm
Wheelbase	1260 mm
Service weight	3030 kg
Axle loading, laden front/rear	4395/435 kg
Axle loading, unladen front/rear	1300/1730 kg
Tyre type	Solid rubber
Tyre size, front	6.5-10mm
Tyre size, rear	5.00-8mm
Wheels, number front/rear (x=drive wheels)	2x/ 2
Tread width, front	905 mm
Tread width, rear	920 mm
Max lift height	4800 mm
Tilt of mast/fork carriage forward/backward	6/10 °
Retracted mast height	1995 mm
Free lift	130 mm
Lift height	["3000"] mm
Height, mast extended	4028 mm
Height of overhead guard (cabin)	2080 mm
Seat height/standing height	1060 mm
Tow coupling height	370 mm
Overall length	2935 mm
Length to face of forks	2015 mm
Overall width	1080 mm
Fork dimensions	40×100×920 mm
A,B Fork carriage class/type A, B	2A
Fork carriage width	1040 mm
Ground clearance, laden, below mast	115 mm
Ground clearance, centre of wheelbase	120 mm
Aisle width for pallets 1000×1200 crossways	3525 Ast
Aisle width for pallets 800×1200 lengthways	3725 Ast
Turning radius	1920 Wa
Travel speed, laden/unladen	8.5/9 km/h
Lifting speed, laden/unladen	0.25/ 0.3 m/s
Lowering speed, laden/unladen	0.43/ 0.45 m/s
Max. gradeability, laden/unladen	10.5/15 %
Service brake	Hydraulic
Parking brake	Mechanical
Drive motor rating S2 60 min	6 kW
Lift motor rating at S3 15%	7.5 kW
Battery nominal capacity	150 Ah
Battery voltage	48 V
Battery type	Li-Ion
Battery weight	115 kg
Type of drive control	AC
Steering design	Hydraulic
Sound pressure level at the drivers ear	70 dB(A)
Dimensions Chart	https://cdn.ep-portal.net/products/attr_131/1758265953813-1rjqw1.webp
Rated Capacities	https://cdn.ep-portal.net/products/attr_130/1758266017591-mv689k.webp

Chris D.

Verified buyer

Since introducing the EFL181 in our workshop, managing the warehouse has become so much smoother. It’s quiet, compact, and incredibly easy to manoeuvre — perfect for our tight spaces. Charging is simple and it lets us work without interruptions. A real step forward from our old diesel forklifts.

Laura P.

Verified buyer

At our nursery we needed a forklift that was easy to use and worked well outdoors. With the EFL181 we found the perfect balance: smooth to drive, stable even on gravel paths, and no more headaches from old combustion engines. Highly recommended.

Ben H.

Verified buyer

We’ve been using the EFL181 for several months now and the difference compared to traditional forklifts is huge. It’s quiet, easy to handle, and simple to use even for new staff. A great solution for a fast-paced warehouse like ours, where every minute counts.

Explore the EFL181

The lithium iron phosphate (LFP) batteries in the EFL181 represent one of the most advanced and reliable energy storage solutions. The EFL181 incorporates this technology to ensure long operating times, fast charging cycles, and no scheduled maintenance, making it an ideal choice for intensive and continuous handling operations.

Versatility & Efficiency

Compact Design

Indoor & Outdoor

Lithium LFP Technology

Our dedicated sales and support network for the EFL181

With the support of EP Equipment distributors spread across the UK, you are guaranteed to receive fast assistance, personalised advice and original parts for your EFL181.

More and more companies are replacing their old equipment with 100% electric solutions like the EFL181, appreciated for their compactness, quiet operation and reduced operating costs.

Choosing the EFL181 means choosing a sustainable alternative, without compromising on power, versatility and autonomy.

Thanks to our network of partners in the UK, you benefit from:

Fast delivery of trucks like the EFL181
Qualified and responsive technical support
Constant availability of original spare parts

Ready to connect with your local dealer?

Get a QuoteRequest Info

FAQs

Common questions people ask about the EFL181.

Is the EFL181 suitable for outdoor use?
Yes. The EFL181 is designed for both indoor operation and uneven outdoor yards, thanks to its high ground clearance, robust chassis, and large pneumatic tyres.
How long does the lithium battery take to charge?
The integrated 48V / 50A charger allows for fast and efficient charging, and the LFP battery supports opportunity charging without causing battery damage.
Does the EFL181 require battery maintenance?
No. The Lithium Iron Phosphate (LFP) battery is completely maintenance-free, eliminating the need for watering, equalising, or battery swaps.
What type of businesses is the EFL181 best suited for?
The EFL181 is ideal for agriculture, landscaping, warehousing, light industry, and small construction businesses that need a compact, reliable, and cost-effective forklift.
